Helix™ Heavy Lift Slings
Helix high performance fiber roundslings are narrow width heavy lift slings designed to fit in lifting hardware with limited space. Helix lifting slings utilizes K-Spec core fiber, the strongest and most trusted roundsling core yarn on the market. Refined over 30 years, K-spec is extremely durable, strong, light weight, and has less than 1% elongation at rated capacity. Helix slings offer high strength capacities while maintaining a narrow profile. This makes Helix the ideal solution when lifting with narrow hardware or limited space. Helix is equipped with an abrasion and chemical resistant HMPE braided jacket that protects the load bearing core yarn. This jacket is braided in the USA. Rifled Cover Technology is braided directly into the HMPE Helix Jacket increasing strength by 17% while reducing sling weight and width.
Helix Sling Design
Introducing the Helix Roundsling, a high-performance, endless roundsling designed to provide exceptional strength and durability with a very narrow sling width footprint for demanding lifting applications. This advanced roundsling features a braided HMPE jacket, offering excellent abrasion resistance and protection for the internal load bearing core, which is made from high-performance K-Spec fibers. Crafted with precision on the Slingmax Roundsling machine, by Slingmax Dealers, the Helix Roundsling ensures consistent quality and reliability, making it the ideal choice for heavy lifts when narrow hardware or trunnions are a factor in the lift plan.
Advantages of Helix Slings
Narrow Width Profile
Helix™ slings offer high strength capacities while maintaining a narrow profile.
This makes Helix the ideal solution when lifting with narrow hardware or limited
space.
High Strength and Durability
Helix™ utilizes K-Spec core fiber, the strongest and most trusted roundsling
core yarn on the market. Refined over 30 years, K-spec is extremely durable,
strong, light weight, and has less than 1% elongation at rated capacity.
Helix Braided HMPE Sling Cover
Helix™ Slings are equipped with an abrasion and chemical resistant HMPE braided jacket that protects the load bearing core yarn. This jacket is braided in the USA. Rifled Cover Technology is braided directly into the HMPE Helix Jacket
increasing strength by 17% while reducing sling weight and width.
Abrasion and Cut Protection
Helix™ roundslings offer excellent protection against cuts and abrasion. The protective outer jackets of Helix slings are made from braided HMPE fibers. Additionally, Helix slings are completely compatible with Slingmax engineered edge and cut protection made from high-performance synthetic materials: Cornermax Pad, Cornermax Sleeve, and Spider Sleeve.
The table below is a sample representation of our Helix slings at a 5:1 Design Factor (DF)/ Safety Factor (SF).
Note: Capacities shown are for one complete sling. Sling ratings based on commercial fittings of equal or greater capacity. Conforms to ANSI/ASME B30.9 chapter 6, NAVFAC P-307 section 14.7.4.3 , Cordage Institute CI-1905, and Web Sling & Tie Down Association WSTDA-RS-1HP . This chart is based on a 5:1 Design Factor (DF); but any other DF can be fabricated. Higher capacity slings are available. CAPACITIES ARE IN POUNDS (LBS.).
